Description
The Victron Energy Battery Monitor BMV-702 BLACK (BAM010702200) from Nomadic Supply Company® is monitor is a high precision battery monitor. It measures battery voltage and current and calculates the battery’s state of charge and the time to go. The BMV has voltage range of 6.5 – 95 V and capacity range of 1 – 9999 Ah.
Victron Energy Battery Monitor BMV-702 BLACK (BAM010702200) Features:
- High-precision battery voltage and current measurement
- State of charge calculation
- Time-to-go indicator
- Programmable visual and audible alarms
- Programmable relay for load management or generator control
- Auxiliary input for temperature, second battery, or midpoint voltage
- 500A quick-connect shunt included
- Color LCD display (on select models)
- Bluetooth connectivity (on BMV-712 Smart)
- Wide voltage range: 6.5 – 95V DC
Victron Energy Battery Monitor BMV-702 BLACK (BAM010702200) Includes:
- Battery monitor display unit
- 500A quick-connect shunt
- Connection kit
- Installation hardware
- User manual and technical documentation
Victron Energy Battery Monitor BMV-702 BLACK (BAM010702200) Specifications:
| Model – BMV-702 | Standard precision monitor without Bluetooth |
| Model – BMV-712 Smart | Bluetooth-enabled precision monitor |
| Voltage Range | 6.5 – 95V DC |
| Capacity Range | 1 – 9999 Ah |
| Shunt Rating | 500A standard |
| Display | LCD color display |
| Connectivity – BMV-702 | Auxiliary input only |
| Connectivity – BMV-712 | Bluetooth + Auxiliary input |
| Alarms | Programmable visual and audible |
| Relay Control | Programmable relay output |
| Temperature Sensor | Optional, via auxiliary input |
| Power Supply | Battery-powered via shunt connection |
Victron Energy Battery Monitor BMV-702 BLACK (BAM010702200) Documents:
BMV-700 Series DatasheetBMV Battery Monitor & SmartShunt Manual (Ed. 3)BMV Battery Monitor & SmartShunt Manual (Ed. 2)BMV Battery Monitor & SmartShunt ManualVictron Energy Battery Monitor BMV-702 BLACK (BAM010702200) Owner’s Manual
