Blue Sea 187-Series 80A Thermal Circuit Breaker Panel Mount (7042-BSS)

Blue Sea 187-Series 80A Thermal Circuit Breaker Panel Mount (7042-BSS)

Original price was: $20.39.Current price is: $12.80.

26 in stock

SKU: ZWJAB557615 Category:

Description

Blue Sea Systems 187 – Series Thermal Circuit Breakers – Panel Mount from Nomadic Supply Company®Blue Sea Systems 80 Amp Circuit BreakerBlue Sea Systems PN:7042

Blue Sea 187-Series 80A Thermal Circuit Breaker Panel Mount (7042-BSS) Features:

  • Combines switching and circuit protection into a single device
  • All components meet SAE J1171 external ignition protection requirements
  • Clear, single lever operation
  • Trip Free design cannot be held ON during fault current condition
  • Waterproof
  • Recessed mounting holes for clean appearance
  • Self-trimming case eliminates the need for mounting panels or trim bezels
  • Round case permits easy installation with standard sized hole saw
  • Large clearance around terminal studs accept heavy gauge wire lugs
  • Robust 5/16 terminals provide high torque connections
  • Large lever with vertical/horizontal orientation provides indication of trip status
  • Ignition protected – safe for installation aboard gasoline powered boats
Blue Sea Systems Specifications
Blue Sea Systems Circuit Breaker Class: Type III – Switchable / Manual Reset – Trip Free
Blue Sea Systems Type: Thermally Responsive Bi-Metal Blade
Blue Sea Systems Case Material: Thermoset Polyester
Blue Sea Systems Voltage Rating: 48 Volts DC Maximum
Blue Sea Systems Interrupt Rating: 5,000 Amperes @12 Volts DC
3,000 Amperes @24 Volts DC
1,500 Amperes @42 Volts DC
Blue Sea Systems Operating Temperature Range: -25C° to +82C°

Blue Sea Systems Manufacturer Part No: 7042 UPC : 632085170424Blue Sea Systems 187-Series Circuit Breaker – Panel Mount 80AModel: 7042-BSS

  • Combines switching and circuit protection into a single device*
  • Clear, single lever operation
  • “Trip Free” design cannot be held “ON” during fault current condition
  • Waterproof
  • Recessed mounting holes for clean appearance
  • Large Clearance around terminal studs accept heavy gauge wire lugs
  • Robust 5/16 M8 terminals provide high torque connections
  • Large lever with vertical/horizontal orientation provides indication of trip status
  • Ignition protected – Safe for installation aboard gasoline powered boats

* Do not use as a switch where high inrush currents are expected.Specifications:

Amperage 80A
Maximum Voltage 48vDC
Mounting Panel Mount
Circuit Breaker Type Thermally responsive Bi-metal blade
Terminal Stud Torque 75 in-lb (8.47 Nm)
Interrupt Capacity 5000A @ 12V3000A @ 24V1500A @ 42V
Minimum Operating Temperature -40° C
Maximum Operating Temperature 85° C
Case Material Thermoset Polyester
Circuit Breaker Class Type III – switchable/manual reset – trip free
Mounting Hole Accept 10 (M5) Screw
Terminal Stud Size 5/16″ – 18
