Blue Sea 187-Series 200 Amp Circuit Breaker Surface Mount

Blue Sea 187-Series 200 Amp Circuit Breaker Surface Mount

Original price was: $23.81.Current price is: $13.28.

65 in stock

SKU: GUOPX289625 Category:

Description

Product

Blue Sea Systems 187-Series Circuit Breaker – Surface Mount 200AModel: 7149-BSS

  • Combines switching and circuit protection into a single device*
  • Clear, single lever operation
  • “Trip Free” design cannot be held “ON” during fault current condition
  • Waterproof
  • Recessed mounting holes for clean appearance
  • Large Clearance around terminal studs accept heavy gauge wire lugs
  • Robust 5/16 M8 terminals provide high torque connections
  • Large lever with vertical/horizontal orientation provides indication of trip status
  • Ignition protected – Safe for installation aboard gasoline powered boats
  • Meets SAE J1171 external ignition protection requirements

* Do not use as a switch where high inrush currents are expected.Specifications

Amperage 200A
Maximum Voltage 48vDC
Mounting Surface Mount
Circuit Breaker Type Thermally responsive Bi-metal blade
Terminal Stud Torque 75 in-lb (8.47 Nm)
Interrupt Capacity 5000A @ 12V3000A @ 24V1500A @ 42V
Minimum Operating Temperature -40° C
Maximum Operating Temperature 85° C
Case Material Thermoset Polyester
Circuit Breaker Class Type III – switchable/manual reset – trip free
Mounting Hole Accept 10 (M5) Screw
Terminal Stud Size 5/16″ – 18
